Yamaha MD-BT01 Bluetooth Wireless MIDI Adaptor
The Yamaha MD-BT01 is a compact Bluetooth wireless MIDI adaptor designed for compatible Yamaha digital pianos, keyboards, synthesisers and other musical instruments equipped with traditional MIDI IN and MIDI OUT terminals.
Once connected to your instrument's MIDI terminals, the MD-BT01 allows MIDI data to be transmitted wirelessly between the instrument and a compatible iPhone, iPad or Mac. This provides a convenient way to use supported music applications without running a MIDI cable directly to your mobile device or computer.
The MD-BT01 uses Bluetooth Low Energy MIDI technology and supports Bluetooth 4.0 compatible devices. Wireless MIDI can be used with supported applications for functions such as MIDI recording, instrument control, music production and communication with compatible Yamaha apps.
Unlike the Yamaha UD-BT01, the MD-BT01 does not require an external USB power adaptor. The two-part adaptor connects directly to the MIDI IN and MIDI OUT sockets on your instrument and receives its operating power from the MIDI connection.
Measuring just 17 x 17 x 67 mm and weighing only 23 g, the MD-BT01 provides a discreet way to add wireless MIDI connectivity to a compatible instrument. Compatibility varies between Yamaha models and applications, so we recommend checking that your particular instrument is listed as MD-BT01 compatible before purchasing.
| Product Type | Bluetooth wireless MIDI adaptor |
| Instrument Connection | MIDI IN and MIDI OUT |
| Connector Type | 5-pin MIDI x 2 |
| Bluetooth Standard | Bluetooth 4.0, GATT compatible |
| MIDI Standard | Bluetooth Low Energy MIDI compliant |
| Transmit Frequency Range | 2402 - 2480 MHz |
| Maximum RF Output Power | 4 dBm |
| Power Supply | Powered from the instrument's MIDI OUT connection |
| External Power Adaptor Required | No |
| Power Consumption | 26 mW |
| Indicators | 2 LEDs |
| Width | 17 mm |
| Height | 17 mm |
| Depth | 67 mm including connector |
| Weight | 23 g |
| Colour | Black |
| Compatible Device Type | Compatible iPhone, iPad and Mac devices with Bluetooth support |
Q: What does the Yamaha MD-BT01 do?
A: The Yamaha MD-BT01 adds Bluetooth wireless MIDI connectivity to compatible musical instruments with traditional MIDI IN and MIDI OUT terminals, allowing MIDI data to be exchanged wirelessly with supported devices and applications.
Q: Which Yamaha instruments are compatible with the MD-BT01?
A: The Yamaha MD-BT01 is compatible with a wide range of selected Yamaha instruments featuring MIDI IN and MIDI OUT connections. Yamaha's compatibility information includes models from ranges such as Genos, Tyros, selected PSR-SX arrangers, MONTAGE, MODX and MODX+, CP and YC stage keyboards and selected digital pianos including the P-515. Examples include Genos2, Genos, PSR-SX920, PSR-SX900, PSR-SX720, PSR-SX700, MODX, MODX+, CP88 and CP73. Compatibility varies by model, so we recommend checking your specific instrument before purchasing.
Q: Will the Yamaha MD-BT01 work with every instrument that has MIDI IN and OUT?
A: No. Having MIDI IN and MIDI OUT sockets does not automatically guarantee compatibility with the MD-BT01. Yamaha confirms compatibility on a model-by-model basis, so your particular instrument should be checked before ordering.
Q: Does the Yamaha MD-BT01 work with Genos2?
A: Yes. Yamaha lists Genos2 as compatible with the MD-BT01, allowing Bluetooth MIDI communication when used with supported devices and applications.
Q: Does the Yamaha MD-BT01 need a power supply?
A: No. The MD-BT01 receives its operating power through the MIDI connection, so a separate USB or mains power adaptor is not required.
Q: How does the Yamaha MD-BT01 connect to my keyboard?
A: The MD-BT01 consists of two connected adaptors that plug into the MIDI IN and MIDI OUT terminals of a compatible instrument. Bluetooth MIDI is then selected from within a supported application on your mobile device or computer.
Q: Does the Yamaha MD-BT01 transmit audio over Bluetooth?
A: No. The MD-BT01 transmits MIDI data rather than Bluetooth audio. It cannot be used to stream music or your instrument's audio signal to Bluetooth speakers or headphones.
Q: Can I use the Yamaha MD-BT01 with an iPad or iPhone?
A: Yes. The MD-BT01 is designed to provide wireless MIDI communication with compatible iPhone and iPad devices using supported Bluetooth MIDI applications.
Q: Can the Yamaha MD-BT01 be used with a Mac?
A: Yes. The MD-BT01 can communicate wirelessly with compatible Mac computers that support the required Bluetooth functionality.
Q: What is the difference between the Yamaha MD-BT01 and UD-BT01?
A: The MD-BT01 is designed for instruments with traditional MIDI IN and MIDI OUT terminals and does not require a separate power adaptor. The UD-BT01 is designed for compatible instruments with a USB TO HOST connection and requires an external USB power source.
Q: Does the Yamaha MD-BT01 use Bluetooth Low Energy?
A: Yes. The MD-BT01 complies with the Bluetooth Low Energy MIDI specification and uses Bluetooth 4.0 technology.
Q: Is the Yamaha MD-BT01 compatible with every Yamaha app?
A: No. Compatibility depends on the instrument, operating system and application being used. We recommend checking the requirements for your particular Yamaha instrument and chosen app before purchasing.
