Building on a legacy of live performance

The PSR-S770 is equipped with a host of powerful performance features, flexible audio playback functions and a Mic/Guitar input, making it ideal for live use on stage, in the studio or at home.

830 Voices, including Super Articulation voices and Organ flutes, 36 Drum/SFX kits, and 480 XG voices
2 Live Controllers for dynamic real-time control assignable to any combination of parameters including filter, arpeggio and more
360 Styles, including all-new DJ styles
Mic/Guitar input for use when singing or collaborating with other performers
New Arpeggio function for instant access to a library of arpeggiated synth phrases and more
Authentic Voices and Styles from around the world
USB audio playback with time stretch, pitch shift, and vocal cancel functions

Features

Get real with your sound

Enjoy realistic Super Articulation Voices, Organ flutes and many other sounds from the legendary Tyros series. The PSR-S770's superb sonic quality, meticulously sampled voices, and a comprehensive suite of effects will take your performances to a new level of authenticity that is sure to satisfy even the most demanding audience.

Powerful features for live performance

The PSR-S770 features two assignable live controllers, a modulation wheel and two assignable foot pedal inputs, ensuring that you have total control over voices, styles, effects and other functions during live performance.
Also, DJ Styles are a new live performance concept, featuring a collection of chord progressions that eliminate the need for continuous chord changes with the left hand. Now you've got both hands free to play melody lines, use the Live Controllers, or even trigger additional external audio with the Multi Pads to add a unique flair to your performance.

Large color LCD display

For simple intuitive control of the powerful features and capabilities of this advanced keyboard, the PSR-S770 comes equipped with a large color LCD that allows you to monitor the status of your instrument at a glance, and gives you easy access to valuable performance functions.

More memory, more sounds

Voice & Style Expansion Packs enable you to customize the PSR-S770 with a wide range of additional content from all over the world. When loaded into the keyboard, you can instantly access authentic new sounds, rhythms and backing in the musical style of your choice. For even more versatility, use Yamaha Expansion Manager version 2.3 (or later) to link the PSR-S770 to your computer.* Yamaha Expansion Manager allows you to create individual expansion data sets containing content from various packs and utilize the 160MB memory capacity on the instrument. You can even create your own voices based on your samples.
*(available during 2015)

Great for singers and guitarists

The PSR-S770 comes equipped with a Mic/Guitar input that allows you to add vocals or guitar to your live performance with ease. Simply plug in a microphone and you can effortlessly assign any of the PSR's versatile effects to the vocals. Or, connect a guitar and adjust the parameters to suit your preference and emulate the sound of your favorite artists or create a sound that's all your own!

USB audio playback with flexible functions

Whether you're enhancing a live performance with backing tracks from your music library or just livening up a party with some Karaoke, the time stretch, pitch shift, and vocal cancel functions of the PSR-S770's USB audio player will add depth and versatility to any musical event.

Chord Tracker

Identify the chord sequence from an audio track instantly with the Yamaha Chord Tracker app!
The Yamaha Chord Tracker app for iPhone and iPad helps practicing and performance by extracting the chord sequence of an audio song stored on your device.

Hear, Try and Compare the Yamaha PSRS770 Arranger Workstation in our showroom

Located in Leicester in the central Midlands and close to Coventry, Nottingham, Derby, Birmingham and Warwick we promise you that a visit to our specialist Digital Piano and Keyboard showroom will not disappoint. Try the full Yamaha range including the PSRS770 Arranger Workstation and compare it with Roland, Casio and Korg all under one roof. Whatever your playing standard our knowledgeable and friendly experts will help guide you through the Keyboard buying process and make sure that you are buying the right instrument for your needs. As ex teachers we are ideally placed to advise and answer any questions you may have. Lifetime support and product tuition with ALL digital pianos.

We sell Digital Pianos and Keyboards. That's it. Nothing else. No distractions and nothing to steal our focus.

Specs

Color/Finish

Body	Color	Metallic Dark Grey

Size/Weight

Dimensions	Width	1002 mm
	Height	148 mm
	Depth	437 mm
Weight	Weight	11.1 kg

Control Interface

Keyboard	Number of Keys	61
	Type	Organ, Initial Touch
	Touch Response	Hard1, Hard2, Medium, Soft1, Soft2
Other Controllers	Pitch Bend	Yes
	Modulation	Yes
	Control Knobs	2 (assignable)
Display	Type	TFT Color Wide VGA LCD
	Size	7 inch
	Color	Color
	Language	English, German, French, Spanish, Italian
Panel	Language	English

Voices

Tone Generation	Tone Generating Technology	AWM Stereo Sampling
Polyphony	Number of Polyphony (Max.)	128
Preset	Number of Voices	830 Voices + 36 Drum/SFX Kits + 480 XG Voices
Preset	Featured Voices	67 S.Art!, 23 Mega Voices, 27 Sweet! Voices, 64 Cool! Voices, 71 Live! Voices, 20 Organ Flutes!
Compatibility	XG	Yes
	GS	Yes (for Song playback)
	GM	Yes
	GM2	Yes
Expandability	Expansion Voice	Yes (approx. 160MB max.)
Part		Right 1, Right 2, Left

Effects

Types	Reverb	52 Presets + 3 User
	Chorus	106 Presets + 3 User
	DSP	295 Presets + 10 User
	Master Compressor	5 Presets + 5 User
	Master EQ	5 Presets + 2 User
	Part EQ	27 parts
	Others	Mic/Guitar effects: Noise Gate x 1, Compressor x 1, 3Band EQ x 1
	Arpeggio	Yes

Accompaniment Styles

Preset	Number of Preset Styles	360
	Featured Styles	322 Pro Styles, 27 Session Styles, 10 DJ Styles, 1 Free Play
	Fingering	Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard
	Style Control	INTRO x 3, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING x 3
Other Features	Music Finder	1,200 Records
Other Features	One Touch Setting (OTS)	4 for each Style
Expandability	Expansion Style	Yes
Compatibility		Style File Format, Style File Format GE

Songs

Preset	Number of Preset Songs	5 Sample Songs
Recording	Number of Songs	Unlimited (depends on the drive capacity)
	Number of Tracks	16
	Data Capacity	approx. 300 KB/Song
	Recording Function	Quick Recording, Multi Recording, Step Recording
Compatible Data Format	Playback	SMF (Format 0 & 1), XF
Compatible Data Format	Recording	SMF (Format 0)

Functions

Registration	Number of Buttons	8
Registration	Control	Registration Sequence, Freeze
Lesson/Guide	Lesson/Guide	Follow Lights, Any Key, Karao-Key, Your Tempo
Lesson/Guide	Performance Assistant Technology (PAT)	Yes
Demo/Help	Demonstration	Yes
Overall Controls	Metronome	Yes
	Tempo Range	5 - 500, Tap Tempo
	Transpose	-12 – 0 – +12
	Tuning	414.8 – 440 – 466.8 Hz
	Octave Button	Yes
	Scale Type	9 types
Miscellaneous	Direct Access	Yes
	Text Display Function	Yes
	Wallpaper Customization	Yes
Voices	Harmony/Echo	Yes (with Arpeggio)
	Panel Sustain	Yes
	Mono/Poly	Yes
	Voice Information	Yes
Styles	Style Creator	Yes
	Style Recommender	Yes
	OTS Information	Yes
Songs	Song Creator	Yes
	Score Display Function	Yes
	Lyrics Display Function	Yes
Multi Pads	Multi Pad Creator	Yes
Audio Recorder/Player	Recording Time (max.)	80 minutes/Song
	Recording	.wav (WAV format: 44.1 kHz sample rate, 16 bit resolution, stereo)
	Playback	.wav (WAV format: 44.1 kHz sample rate, 16 bit resolution, stereo), .mp3 (MPEG-1 Audio Layer-3: 44.1/48.0 kHz sample rate, 64-320 kbps and variable bit rate, mono/streo)
	Time Stretch	Yes
	Pitch Shift	Yes
	Vocal Cancel	Yes

Storage and Connectivity

Storage	Internal Memory	approx. 13 MB
Storage	External Drives	USB Flash Memory (via USB to DEVICE)
Connectivity	Headphones	Yes
	FOOT PEDAL	1 (SUSTAIN), 2 (ARTICULATION), Function Assignable
	Microphone	Microphone/Guitar x 1
	MIDI	IN, OUT
	AUX IN	Stereo mini jack
	LINE OUT	L/L+R, R
	USB TO DEVICE	Yes
	USB TO HOST	Yes

Amplifiers and Speakers

Amplifiers		15 W x 2
Speakers		13 cm x 2 + 5 cm x 2

Power Supply

Power Supply		PA-300C or an equibalent recommended by Yamaha
Power Consumption		19 W
Auto Power Off Function		Yes

Accessories

Included Accessories		Owner's Manual, Online Member Product Registration, Music Rest, AC Adaptor(may not be include depending on your area. Check with your Yamaha dealer.)
